SPECIFICATIONS:
OVERVIEW
Dimensions
442 x 200 x 44 mm (17.4 x 7.9 x 1.7")
Port Layout
1 GbE RJ45: 16 (8 PoE+) (1G/100M/10M)
1G SFP: 2 (1G)
Max. PoE Output
Up to PoE+
Total PoE Availability
42W
Form Factor
Rack mount (1U)
PERFORMANCE
Switching Capacity
36 Gbps
Total Non-Blocking Throughput
18 Gbps
Forwarding Rate
27 Mpps
Supported VLANs
1,000
MAC Address Table Size
8,000
Packet Buffer Size
0.5 MB
Access Lists
IPv4: 128
MAC: 128
LAYER 2 FEATURES
LACP Port Aggregation
✓
STP & RSTP
Advanced IGMP Configuration(Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection
HARDWARE
PoE Ports
PoE+: 8
Max. PoE Wattage per Port by PSE
PoE: 15.4W
PoE+: 32W
Max. Power Consumption
18W (Excluding PoE Output)
60W (Including PoE Output)
Power Method
Universal input, 100—240V AC, 50/60 Hz
Power Input Method
AC input
Power Supply
AC/DC, internal, 60W
Supported Voltage Range
100—240V AC
Management
Ethernet AR
Heat Dissipation (Excluding PoE Output)
61.416 BTU/hr
Weight
Without mounting brackets: 2.8 kg (6.2 lb)With mounting brackets 2.9 kg (6.4 lb)
Enclosure Material
SGCC steel
Mount Material
Supported Rack Depth
400~1200 mm (15.7-47.2")
LCM Display
1.3" touchscreen
ESD/EMP Protection
Air: ± 16kV, contact: ± 12kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, Anatel
SOFTWARE
Application Requirements
UniFi Network: Version 7.2.94 and later
