Aten 2 Port USB-C Gen 2 Sharing Switch with Power Pass-through (US3342-AT)

Connectors

Computer

USB   3.2 Gen 2 Type-C Female (Black) x 2

Device

USB   3.2 Gen 2 Type-A Female (Blue) × 3

USB   3.2 Gen 2 Type-C Female (black) x 1

Power

USB   Type-C Female x 1, supports USB PD3.0 at 5V, 9V, 15V and 20V output

Port   Selection

Input

Remote   port selector / software

Power   Consumption

DC5V:0.43W:428BTU

LEDs

Selected

2   (White)

Environmental

Operating Temperature

0-40?

Storage Temperature

-20-60?

Humidity

0–80%   RH, Non-condensing

Physical   Properties

Housing

Aluminum

Weight

0.26   kg ( 0.57 lb )

Dimensions (L x W x H)

14.30   x 9.00 x 2.38 cm

(5.63   x 3.54 x 0.94 in.)

Note

For   some of rack mount products, please note that the standard physical   dimensions of WxDxH are expressed using a LxWxH format.

Package   Contents

·          1x US3342 2-Port USB-C Gen 2 Sharing Switch with   Power Pass-through

·          2x USB-C 3.2 Gen 2 Cables

·          1x Remote Port Selector

·          1x User Instructions
