SPECIFICATIONS:
CPU |
| CPU Model | Realtek RTD1296 | CPU Architecture | ARM64 64-bit | CPU Frequency | Quad-Core 1.4GHz | MEMORY |
| Memory | 1GB DDR4 | Memory Expandable up to | not expandable | Flash Memory | 8GB eMMC | STORAGE |
| Drive Bays | 4 | Compatible Drive Type | 3.5" SATA HDD | Maximum Drive Bays with Expansion Unit | 12 | EXTERNAL PORTS |
| Expansion | 2x USB 3.2 Gen 1 | Network | 1x 2.5 Gigabit Ethernet (2.5G/1G/100M) | Multimedia Output | N/A | OTHERS |
| System Fan | 1x 120mm | Power Supply Unit / Adapter | 90W x1 | Input Power Voltage | 100V to 240V AC | Certification | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC | OPERATION |
| Power Consumption | 22.8W (Operation) 9.41W (Disk Hibernation); | Noise Level | 19.7dB (HDD idle) | Operation Temperature | 0°C~40°C (32°F~104°F) | Storage Temperature | -20°C~70°C (-4°F~158°F) | Humidity | 5% to 95% RH | SIZE AND WEIGHT |
| Size | 165(H) x 164(W) x 218(D) mm | Weight | 1.57 kg / 3.45 lbs | SOFTWARE |
| Supported OS | Windows 10, 11, Server 2016, Server 2019, Server 2022 macOS UNIX, Linux, and BSD | Supported Languages | Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česk, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย | Supported Browsers | Firefox Chrome Safari Microsoft Edge | PACKAGE |
| Package Weight | 2.77 kg / 6.09 lbs | Package Size | 237(H) x 323(W) x 214(D) mm | Package Contents | AS1104T Unit x1 Quick Installation Guide AC Power Cord x1 AC Power Adapter x1 RJ-45 LAN Cable(Cat 5e) x1 Thumb Screw (for 3.5" HDD) x16 |
|
