Please Check Modem/Router Compatibility with your Service Providers Before Purchasing
SPECIFICATIONS:
OVERVIEW |
| Dimensions | 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2") | Max. WAN Port Count | 4 | Default WAN Ports | (1) 2.5 GbE RJ45 | Port Layout | 2.5 GbE RJ45 5 (2.5G/1G/100M/10M) | IDS/IPS Throughput | 2.3 Gbps | Form Factor | Compact desktop | SECURITY |
| Stateful Firewall | ✓ | Application-Aware Layer 7 Firewall | ✓ | DPI & Traffic Identification | ✓ | Zone-Based Firewall Advanced Filtering (Regions, Domains, Apps) | ✓ | Content Filtering | ✓ | Intrusion Prevention (IPS/IDS) | ✓ | Ad Blocking | ✓ | IDS/IPS Signatures | 55,000+ With CyberSecure | VPN & SD-WAN |
| License-Free SD-WAN | ✓ | Site-to-Site VPN | Site Magic: ✓ IPsec: ✓ OpenVPN: ✓ | VPN Server | Teleport Zero-Configuration VPN: ✓ WireGuard: ✓ OpenVPN: ✓ L2TP: ✓ | VPN Client | OpenVPN: ✓ WireGuard: ✓ | NETWORKING |
| Multi-WAN Load Balancing | ✓ | Dynamic Routing | OSPF: ✓ | Advanced QoS | ✓ | Multicast DNS (mDNS) | ✓ | Advanced NAT (SNAT / DNAT / Masquerade / NAT Pooling / 1-to-1 NAT) | ✓ | Integrated RADIUS Server | ✓ | RADIUS over TLS (RadSec) | ✓ | Additional Internet Failover with UniFi LTE Backup | ✓ | Internet Quality and Outage Reporting | ✓ | MAC Address Table Size | 2,000 | Virtual Network Override | ✓ | All Traffic Flows | ✓ | HARDWARE |
| Max. Power Consumption | 9.6W | Power Method | USB type C (5V DC/3A) | Power Supply | USB type C (5V DC/3A) (Adapter included) | Supported Voltage Range | 100–240V AC | Heat Dissipation | 33 BTU/hr | Processor | Quad-core ARM® Cortex®-A53 at 1.5 GHz | System Memory | 2 GB | Weight | 520 g (1.1 lb) | Enclosure Material | Polycarbonate | Management | Ethernet | Bluetooth | LEDs | Ethernet | ✓ | System | ✓ | Button | (1) Factory reset | ESD/EMP Protection | Air: ± 8kV, contact: ± 4kV | Ambient Operating Temperature | -10 to 40° C (14 to 104° F) | Ambient Operating Humidity | 5 to 95% noncondensing | NDAA Compliant | ✓ | Certifications | CE, FCC, IC, Anatel: 04873-25-08356 | SOFTWARE |
| Application Requirements | UniFi Network: Version 8.1.113 and later |
|
