SPECIFICATIONS:
OVERVIEW
Dimensions
212.9 x 99.4 x 33.5 mm (8.4 x 3.9 x 1.3")
Port Layout
2.5 GbE RJ45: 8 (All PoE++) (2.5G/1G/100M/10M)
10 GbE RJ45: 1 (PoE+++) (10G/5G/2.5G/1G/100M)
10G SFP+: 1 (10G/1G)
Max. PoE Output
Up to PoE++
Total PoE Availability
PoE+++ input: 76W PoE++ input: 46W PoE+ input: 16W 210W AC adapter input: 196W
Form Factor
Compact Desktop, wall, DIN, magnetic
PERFORMANCE
Switching Capacity
60 Gbps
Total Non-Blocking Throughput
30 Gbps
Forwarding Rate
45 Mpps
Supported VLANs
256
MAC Address Table Size
4,000
LAYER 2 FEATURES
STP & RSTP
✓
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
Port Isolation
Port Mirroring
Jumbo Frames
Loop Protection
HARDWARE
PoE Ports
PoE++: 8
Max. PoE Wattage per Port by PSE
PoE: 15.4W
PoE+: 32W
PoE++: 64W
Max. Power Consumption
14W (Excluding PoE output) with PoE input 17W (Excluding PoE output) with AC adapter input 210W (Including PoE Output)
Power Method
(1) AC/DC adapter (Excluded)
(1) PoE+++
Power Input Method
DC Input
PoE
Supported Voltage Range
50—57V DC/PoE
Management
Ethernet
Weight
567 g (20 oz)
Enclosure Material
Polycarbonate
Mount Material
Ambient Operating Temperature
-20 to 45° C (-4 to 113° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC
SOFTWARE
Application Requirements
UniFi Network
Version 9.0.114 and later
