STORAGE |
Disk Slot Number | 5 |
Compatible Disk Types | 3.5" SATA HDD 2.5" SATA SSD |
RAIDs Supported（RAID hardware switch mode） | SINGLE DISK,RAID 0,RAID 1,RAID 5,RAID 10 |
RAID Expansion/Migration | / |
RAID Hot Spare | √（The hard drives added in RAID 1/5/10 modes are the listed hot spare drives.） |
Maximum Internal Raw Capacity | 120TB(24 TB HDD x 5, RAID 0 Array) |
Fan mode | PWM Smart Temperature Control |
Hard Drive S.M.A.R.T. | √ |
TRIM | / |
EXTERNAL PORTS |
Data transmission interface | USB-C x 1 |
Data transmission cable | USB Cable A to C |
Hard Drive Format | NTFS,APFS,Mac OS,FAT32,EXT4,exFAT |
Reading/writing Speed (max.)
Test conditions:
The test drives are 5 Western Digital 8TB WD80EFBX;
the test computer is a Mac mini with Apple M4 chip, running macOS 15.1.1;
the test software is AJA System Test Lite. | RAID5 Mode,Write: 231MB/s;Read: 248MB/s RAID0 Mode,Write: 238MB/S;Read: 244MB/s RAID10 Mode,Write: 241MB/s;Read: 248MB/s RAID1 Mode,Write: 188MB/s;Read: 187MB/s SINGLE Mode,Write: 188MB/s;Read: 187MB/s |
OPERATING SYSTEM |
Supported OS | Windows 7.8.10.11,Windows Server,Mac OS, Linux Ubuntu,KylinV10 SP1 |
RAID Manager Client | Supports Windows 7, 8, 10, 11, and Windows Server Not supported on Mac OS, Linux Ubuntu, and Kylin V10 SP1. |
APPEARANCE |
Size (H*W*D) | 227 x 225 x 136 mm |
Weight | net weight: 2.16Kg Gross Weight: 3.64 Kg |
Enclosure Material | Aluminum Alloy |
POWER SUPPLY |
AC Input Voltage | DC 12V (90W) |
Current Frequency | 50/60 HZ, Single Phase |
Power Consumption | 45.5W (5 x 8TB Western Digital WD80EFBX hard drives in read/write state) 5.2W (5 x 8TB Western Digital WD80EFBX hard drives in hibernation) |
Working Temperature | 0°C ~ 40°C (32°F ~ 104°F) |
Relative Humidity | 5% ~ 95%RH |
Storage Temperature | -20°C ~ 60°C (-5°F ~ 140°F) |
Certificate | CCC、CE、FCC、UL |
ENVIRONMENTAL PROTECTION AND PACKAGING |
Environment | RoHS compliance |
Package Contents | Host unit (x1) Quick Installation Guide (x1) Power adapter (x1) Power cord (x1) USB Cable A to C (0.8m x1) |
