Terra Master 3+2 Bay Hybrid Network Storage (F2-425 Plus)

Processor Model

Intel® N150 Quad-Core

Processor Architecture

x86 64-bit

Processor Frequency

Max burst up to 3.6 GHz

CPU Single-Core Score

/

Hardware Transcoding Engine

H.264, H.265, MPEG-4, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60

Hardware Transcoding Engine

√

System Memory

8 GB DDR5 non-ECC SODIMM

Pre-installed Memory Module

8 GB DDR5 non-ECC SODIMM (1x 8 GB)

Total Memory Slot Number

1 (DDR5 SODIMM)

Maximum Supported Memory

32 GB DDR5 non-ECC SODIMM

Disk Slot Number

2

Compatible Drive types

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Maximum Internal Raw Storage Capacity

60 TB (30TB x2) (Capacity may vary by RAID types)

M.2 2280 NVMe Slot

3 (PCIe 3.0 x1）

Drive Hot Swap

√

FILE SYSTEM

Internal Drive

Btrfs, EXT4

External Drive

EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS

RJ-45 5GbE Network Port

2

USB3.2 Host Port

3  x   Type A + 1  x Type C

HDMI

1 x HDMI

APPEARANCE

Size (H*W*D)

150*122*219 mm

Packaging Size (H*W*D)

186*217*277 mm

Weight

Net Weight: 2.2 Kg , Gross Weight: 3.1 Kg

System Fan

80 x 80 x 25mm  1PCS

Fan Mode

Smart, High speed, Middle speed, Low speed

Noise Level

20.0 dB(A) （Using 2 SATA HDDs/SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m）

Power Supply

48 W

Redundancy Power Supply

/

AC Input Voltage

100V - 240V AC

Current Frequency

50/60 Hz, Single frequency
