CAMERA
Image Sensor
1/3 Progressive Scan CMOS sensor
Day and Night
ICR type
LENS
Focal Length
4mm
Aperture
F2.0
FOV
Horizontal : 83.3°, Vertical : 51.3°, Diagonal : 90.6°
ILLUMINATOR
Supplementary Light
2 IR Lights
Supplementary Light Distance
Up to 10 m/32 ft (depending on environment)
IR Wavelength
850nm
Night Vision Mode
Black & White Mode
VIDEO
Video Encoding Format
H.265, H.264
Main Stream Resolution
2880 x 1620 ， 2560 x 144 2304 × 1296, 1920 × 1080, 1280 × 720
Sub Stream Resolution
640 x 360 , 352 x 288 , 320x240
Frame Rate
1-30fps,Default 20fps
Bit Rate
512kbps -- 4096kbps
Bit Rate Control
CBR,VBR
AUDIO
Audio Encoding Format
G.711A, G.711U, AAC
Audio Sampling Rate
8 kHz
Audio Communication
Two-way Audio, One-touch Call
Image Enhancement
DWDR, BLC, HLC, 3D DNR
Privacy Mask
4 Areas
NETWORK
Ethernet Port
1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port
ONVIF
Support
Protocols
TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP
Client
TDSEE (mobile phone), TDSEE STUDIO (PC)
Web Browser
Chrome, Edge, Opera
PAN&TILT
Pan Movement Range
0°--355°
Tilt Movement Range
-65°--90°
Preset
6
Patrol
Panoramic Patrol, Preset Patrol
WI-FI
Antenna
Internal antenna
Wireless Standard
IEEE 802.11 b/g/n/ax
Transmission Rate
Up to 287Mbps
Channel Width
20/40 MHz
Modulation
DSSS/OFDM/OFDMA
Frequency Band
2.4GHz: 2412MHz-2472MHz(CH1-CH13)
Transmit Power
2.4GHz: <0.1W(EIRP)
Security
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
ALARM
Smart Detection
Motion Detection, Tampering Detection, Human Detection, Cry Detection
Smart Linkage
Sound&light Alert, Human Tracking
DIY Audio
3 Customized Audios
INTERFACE
Audio Input
Built-in MIC, adjustable microphone volume
Audio Output
Built-in Speaker, 73 dBA (Alarm sound at 1 meter), adjustable sound level
Storage
Built-in Micro SD Card Slot, Up to 512GB
Reset Button
Support
LED Indicator
Dual Color (red & blue)
LED Indicator
GENERAL
Power
5 V 1A, Type-C Power Plug
Material
Plastic
Smart Integration
Amazon Alexa
Product Dimension
103mm x 88mm x 88mm (4.1'' ×3.5'' × 3.5'')
Package Dimension
100mm x 100mm x 165mm (4.0'' ×4.0'' × 6.5'')
Product Weight
200g (0.44lb)
With Package Weight
370g (0.82lb)
Installation Method
Desktop, Ceiling Mounting
Certification
CE, RoHS, FCC, RCM, UKCA
Temperature
Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)
Humidity
Operating Humidity: 10% ~ 95% RH (non-condensing)
Storage Humidity: 3% ~ 95% RH (non-condensing)
Package Contents
Camera
Power Adapter (cord length: 1.5m)
Installation Template
Mounting Bracket
Mounting Accessories Kit
Quick Installation Guide
