ATX (12" x 9.6), Micro-ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7")
Drive bay
Internal:
3.5" x 1 / 2.5" x 1 / 2.5" x 2 [1]
3.5" x 1
2.5" x 1
[1]When installing two 2.5" SSDs in this position, ensure the connectors face the rear to prevent interference.
Cooling system
Rear:
120mm x 1
(120mm x 1 ARGB fan included)
Top:
120mm x 3 / 140mm x 2
Internal:
Motherboard Tray:120mm x 2(120mm x 2 ARGB fans included)
PSU Shroud:Top:120mm x 3
Front:80mm x 2
Radiator support
Rear:
120mm
Top:
120mm / 140mm / 240mm / 280mm / 360mm[2]
Internal:
Motherboard Tray:240mm[3]
[2] When mounting a 360mm radiator in this position, ensure the inlet and outlet tubes are orientated toward the front to prevent interference.
[3] When mounting a 240mm radiator in this position, graphics card clearance is limited to 281mm, including power connectors. Ensure the fans are installed between the radiator and motherboard tray to accommodate this restriction.
Limitation of CPU cooler
173mm
Expansion slot
7
Limitation of expansion card
Length:410mm
Width:179mm
Power supply
Standard PS2 (ATX)
Limitation of PSU
200mm
Front I/O port
USB Type-C x 1
USB 3.0 x 2
Audio x 1
Mic x 1
Dimension
220mm (W), x 491.5mm (H), x 427.6mm (D), 46.24 liters
8.66" (W), x 19.35" (H), x 16.83" (D), 46.24 liters
Remark
[1]When installing two 2.5" SSDs in this position, ensure the connectors face the rear to prevent interference.
[2]When mounting a 360mm radiator in this position, ensure the inlet and outlet tubes are orientated toward the front to prevent interference.
[3] When mounting a 240mm radiator in this position, graphics card clearance is limited to 281mm, including power connectors. Ensure the fans are installed between the radiator and motherboard tray to accommodate this restriction.
