MAXSUN Terminator B850M Dark WiFi AM5 Micro ATX Motherboard (MS-Terminator-B850M-DARK-WIFI)

CPU Socket

AMD AM5 socket, compatible with AMD Ryzen™ 7000, 8000, and 9000 series processors

Chipset

AMD B850 Chipset

Memory

4× DIMM DDR5 slots, up to 192GB total capacity

Supports dual-channel memory architecture

Supports AMD EXPO memory overclocking

Supported frequencies:

4800 / 5200 / 5600(OC) / 6000(OC) / 6400(OC) / 6800(OC) / 7000(OC) / 7200(OC) / 7600(OC) / 7800(OC) / 8000(OC) MHz

Display Outputs

1× DP port, supports up to 4K @ 60Hz resolution

1× HDMI 1.4 port, supports up to 4K @ 30Hz resolution

Expansion Slots

1× PCIe x16 slot (supports PCIe 5.0 x16 mode)

1× PCIe x16 slot (supports PCIe 4.0 x4 mode)

Audio

Integrated Realtek ALC897 audio codec

Networking

1× Realtek RTL8125D 2.5G Ethernet port

1× MediaTek MT7922 wireless module: supports Wi-Fi 6E and Bluetooth v5.2

Storage

M.2_A slot (Key M): supports PCIe 5.0 x4/x2 mode, 2280 length

M.2_B slot (Key M): supports PCIe 5.0 x4/x2 mode, 2280 length

M.2_C slot (Key M): supports PCIe 4.0 x2 mode, 2280 length

USB

Onboard USB (7 total):

1× USB 5G 19-pin header (supports 2 additional USB 5G ports)

2× USB 2.0 9-pin headers (support 4 additional USB 2.0 ports)

1× USB 10G Type-C front panel port

Rear I/O USB (9 total):

4× USB 5G Type-A ports

4× USB 2.0 Type-A ports

1× USB 10G Type-C port

Other   Features

1× 24-pin ATX power connector

2× 8-pin +12V CPU power connectors

1× 4-pin CPU_FAN header

1× 4-pin PUMP header

2× 4-pin SYS_FAN headers

2× 3-pin 5V ARGB headers

1× CLR_CMOS quick-access   button
