Keychron K4 HE White QMK Wireless Magnetic Keyboard Side Wood Frame Edition Gateron Double-Rail - Nebula Switch (KBKCK4HQ1)
Keychron K4 HE: 4000 mAh battery, 2.4 GHz/Bluetooth 5.2/Type‑C wired, Gateron double‑rail magnetic hot‑swappable switches, north‑facing RGB, adjustable 0.2‑3.8 mm actuation, rapid trigger, NKRO, 1000 Hz polling, aluminum‑wood frame.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
Length
377.1 mm
Width
126.4 mm
Front Height
31.7 mm (incl. keycap)
Back Height
40.9 mm (incl. keycap)
Weight
Approx. 1066 g
Keycaps
OSA Double-shot keycaps, not shine-through
Frame Material
Aluminum + wood
Bottom Case Material
ABS Plastic
Stabilizer
Plate-Mounted Stabilizer
Switch
Gateron double-rail magnetic switch
MCU
ARM Cortex-M4 32-bit STM32F402RC (256KB Flash)
Angle
5° / 8° / 11°
Backlight
North-facing RGB LED
Plate Material
Aluminum
Sensitivity
0.1 mm
Rapid Trigger
Yes
Adjustable Actuation Points
0.2 - 3.8 mm
Dynamic Keystrokes
4-in-1 action keys
Mount Style
Tray Mount Design
Cable
Type-A to Type-C cable
Connectivity
2.4 GHz / Bluetooth / Type-C wired
Bluetooth Version
5.2
Bluetooth Device Name
Keychron K4 HE
Battery
4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off)
Up to 110 hours (Lab test results may vary based on actual use)
N-Key Rollover (NKRO)
Yes for both wireless and wired modes
Hot-swappable Support
Yes, compatible with Gateron double-rail magnetic switch only.
Polling Rate
1000 Hz (Wired and 2.4 GHz) / 125Hz (Bluetooth)
Operating Environment
-10 to 50℃
Product Name:
Keychron K4 HE White QMK Wireless Magnetic Keyboard Side Wood Frame Edition Gateron Double-Rail - Nebula Switch (KBKCK4HQ1)
