Keychron K10 HE Wireless Magnetic Switch Special Edition White Keyboard - Gateron Double-Rail Magnetic Nebula Switch (KBKCK10HQ1)
10‑key rollover, hot‑swappable Gateron double‑rail magnetic switches with adjustable 0.2‑3.8 mm actuation, rapid‑trigger, 3‑angle tilt, north‑facing RGB, Bluetooth 5.2/2.4 GHz, 4000 mAh battery (120 h), aluminum‑wood frame, OSA double‑shot keycaps.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
Length
444.6mm
Width
129.2 mm
Front Height
32.94 mm (incl. keycap)
Back Height
39.52 mm (incl. keycap)
Weight
Approx. Approx. 1310 g
Keycaps
OSA Double-shot keycaps, not shine-through
Frame Material
Aluminum + wood
Bottom Case Material
ABS Plastic
Stabilizer
Plate-Mounted Stabilizer
Switch
Gateron double-rail magnetic switch
MCU
ARM Cortex-M4 32-bit STM32F402 (256KB Flash)
Angle
3.5º/ 7.7º/ 11º
Backlight
North-facing RGB LED
Plate Material
Aluminum
Sensitivity
0.1 mm
Rapid Trigger
Yes
Adjustable Actuation Points
0.2 - 3.8 mm
Dynamic Keystrokes
4-in-1 action keys
Mount Style
Tray Mount Design
Cable
Type-A to Type-C cable
Connectivity
2.4 GHz / Bluetooth / Type-C wired
Bluetooth Version
5.2
Bluetooth Device Name
Keychron K10 HE
Battery
4000 mAh Rechargeable li-polymer battery
Wireless Working Time (Backlit off)
Up to 120 hours (Lab test results may vary based on actual use)
N-Key Rollover (NKRO)
Yes for both wireless and wired modes
Hot-swappable Support
Yes, compatible with Gateron double-rail magnetic switch only.
Polling Rate
1000 Hz (Wired and 2.4 GHz) / 125Hz (Bluetooth)
Operating Environment
-10 to 50℃
Product Name:
Keychron K10 HE Wireless Magnetic Switch Special Edition White Keyboard - Gateron Double-Rail Magnetic Nebula Switch (KBKCK10HQ1)
