AMD Radeon RX 9070 XT with 16 GB GDDR6 (256-bit, 20 Gbps), 4096 stream processors, up to 3080 MHz boost, PCIe 5.0, HDMI 2.1b & 3× DP 2.1a (4‑display), RGB Aura Sync, 3×8‑pin, 850 W PSU recommended.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
Graphic Engine
AMD Radeon™ RX 9070 XT
Bus Standard
PCI Express 5.0
OpenGL
OpenGL®4.6
Video Memory
16GB GDDR6
Engine Clock
OC mode(GPU Tweak III): up to 3080 MHz (Boost Clock)/up to 2540 MHz (Game Clock)
Default mode: up to 3060 MHz (Boost Clock)/up to 2520 MHz (Game Clock)
Stream Processors
4096
Memory Speed
20 Gbps
Memory Interface
256-bit
Resolution
Digital Max Resolution 7680 x 4320
Interface
Yes x 1 (Native HDMI 2.1b)
Yes x 3 (Native DisplayPort 2.1a)
HDCP Support Yes (2.3)
Maximum Display Support
4
NVlink/ Crossfire Support
No
Accessories
1 x TUF certificate of Reliability
1 x TUF Gaming Graphics Card Holder
1 x TUF Velcro Hook & Loop
1 x TUF Fridge Magnet
1 x Thank you card
1 x Speedsetup Manual
Software
ASUS GPU Tweak III & Drivers: please download all software from the support site.
Dimensions
330 x 140 x 62.5 mm
13 x 5.5 x 2.5 inch
Recommended PSU
850W
Power Connectors
3 x 8-pin
Slot
3.125 Slot
AURA SYNC
RGB
Note
* Our wattage recommendation is based on a fully overclocked GPU and CPU system configuration. For a more tailored suggestion, please use the “Choose By Wattage” feature on our PSU product page: https://rog.asus.com/event/PSU/ASUS-Power-Supply-Units/index.html
* ‘Game Clock’ is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary.
* ‘Boost Clock’ is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads.
