OVERVIEW |
|
Built-In Omada OS Applications | Network Application |
Managed Omada Devices | Recommended for up to 30 devices |
Client Capacity | Recommended for up to 300 connected clients |
Interface | • 1× 2.5G RJ45 WAN port • 4× 2.5G RJ45 LAN/WAN ports • Up to 4 simultaneous WAN ports |
IPS Throughput | 2,183 Mbps |
Site-to-Site VPN Throughput | 1,023 Mbps* * Performance data is based on IPsec VPN. |
Management | Cloud, local, and Omada App management |
Mounting | • Desktop • Wall-mount (magnetic-mount plate sold separately) • Rack-mount (rackmount kit sold separately) |
Dimensions | 6.3 × 5.12 × 1.24 in (160 × 130 × 31.5 mm) |
BUILT-IN OMADA CONTROLLER§ |
|
Cloud Access | √ |
Local Management | √ |
Omada App | √ |
Multi-Site Management | Via the Omada Cloud Management Platform |
Restore & Backup | √ |
Automatic Device Discovery | √ |
Network Topology | √ |
Dashboard | √ |
Device List / Client List | √ |
Logs / Alerts / Events | √ |
Batch Firmware Upgrade | √ |
Health Monitoring | √ |
Internet Activity | √ |
Captive Portal | √ |
RADIUS / LDAP Authentication | √ |
802.1X Authentication | √ |
OUI-Based VLAN | √ |
Diagnostics Tools | Ping Test, Packet Capture, Terminal, Cable Test, Interference Detection, Remote Access, IntelliRecover, Port Mirroring |
SNMP | v1/v2c/v3 |
SECURITY |
|
IDS/IPS | √ |
DPI | √ |
Application-Based ACL | √ |
Content Filtering | √ |
Ad Blocker | √ |
Safe Search | √ |
DNS Security | √ |
Firewall | √ |
Attack Defense | √ |
ARP Inspection | √ |
VPN & SD-WAN |
|
Omada LightLink VPN | √ |
Site-to-Site VPN | WireGuard VPN / IPsec VPN |
VPN Server | WireGuard VPN / OpenVPN / IPsec VPN / SSL VPN / L2TP VPN / PPTP VPN |
VPN Client | WireGuard VPN / OpenVPN / L2TP VPN / PPTP VPN |
SD-WAN | Full Mesh Mode |
VPN Throughput | • Omada LightLink VPN: 527 Mbps • IPsec VPN: 1,023 Mbps • WireGuard VPN: 605 Mbps • OpenVPN: 223 Mbps • L2TP VPN: 892 Mbps • PPTP VPN: 193 Mbps • SSL VPN: 250 Mbps |
NETWORKING |
|
WAN Connection | Static IP / Dynamic IP / PPPoE / PPTP / L2TP / MAP-E / DS-Lite |
Multi-WAN Failover & Load Balancing | √ |
DHCP Server | √ |
VLAN Segmentation | √ |
Bandwidth Control | √ |
QoS | √ |
Static Routing | √ |
Policy Routing | √ |
NAT | Port Forwarding / Virtual Server / DMZ / ALG / UPnP / One-to-One NAT / Disable NAT |
Dynamic DNS | TP-Link DDNS, 3rd-party DDNS, custom DDNS |
IPv6 | Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Pass-Through / Non-Address Mode |
Bonjour / mDNS | √ |
IGMP v2/v3 Proxy | √ |
HARDWARE |
|
Touchscreen | 2.51-inch color LCM touchscreen |
Button | Reset button |
CPU | Quad-core ARM Cortex-A53 @ 2.0 GHz |
Memory | 2 GB DDR4 |
Storage | 64 Mbit NOR flash + 16 GB eMMC |
Power Supply | USB-C power adapter, 100–240 V AC, 50/60 Hz input, 5 V DC / 3 A output |
Max Power Consumption | 8.18 W, with power adapter |
Enclosure | Polycarbonate |
LED | Ethernet |
Fan | Fanless |
Net Weight | 1.12 lb (510 g) |
Surge Protection | 4 kV surge protection |
ESD Protection | ±8 kV (Air), ±4 kV (Contact) |
Onboarding | Bluetooth or Ethernet |
Certifications | CE, FCC, RoHS |
Environment | • Operating Temperature: 14 °F to 104 °F (-10 °C to 40 °C) • Storage Temperature: -40 °F to 158 °F (-40 °C to 70 °C) • Operating Humidity: 10% to 90% RH, non-condensing • Storage Humidity: 5% to 90% RH, non-condensing |
