SPECIFICATIONS:
HARDWARE FEATURES
Interface
• 8× 2.5 Gbps RJ45 Ports
• 2× 10 Gbps SFP+ Slots
• Auto-Negotiation/Auto MDI/MDIX
Fan Quantity
Fanless
Installation
• Desktop
• Wall Mount
Physical Security Lock
√
Power Supply
DC Power Adapter (Output: 12 VDC / 1.5 A)
Dimensions ( W x D x H )
8.2 × 5.0 × 1.0 in (209 × 126 × 26 mm)
Surge Protection
±6 kV
PERFORMANCE
Switching Capacity
80 Gbps
Packet Forwarding Rate
59.52 Mpps
MAC Address Table
16K
Packet Buffer Memory
640 KB
Jumbo Frame
10 KB
SOFTWARE FEATURES
Quality of Service
• Port-based/802.1p/DSCP QoS
• 8 Priority Queues
• Priority Schedule Mode
- WRR (Weighted Round Robin)
• Queue Weight Config
• Bandwidth Control
- Port-Based Rating Limit
• Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control△
L2 Features
• Static Link Aggregation
• Loop Prevention / Loopback Detection
• Flow Control
- 802.3x Flow Control
• Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
• Port Statistics
- Port Mirror Status
- Traffic Statistics
• 802.1ab LLDP
L2 Multicast
• IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
VLAN
• MTU VLAN
• Port-Based VLAN
• 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
Transmission Method
Store-And-Forward
MANAGEMENT FEATURES
Omada App
Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management
• Omada Cloud-Based Controller
• Omada Hardware Controller
• Omada Software Controller
Cloud Access
Zero-Touch Provisioning
Yes. Requires the use of Omada Cloud-Based Controller
Management Features
• Web-based GUI
• DHCP Client
• Cable Diagnostics
• Automatic Device Discovery
• Batch Configuration
• Batch Firmware Upgrading
• Unified Configuration
OTHERS
Certification
FCC, CE, RoHS
Package Content
• ES210X-M2
• Power Adapter
• Rubber Feet
• Installation Guide
Environment
• Operating Temperature: -5℃~40℃ (23℉~104℉)
• Storage Temperature: -40℃~70℃ (-40℉~158℉)
• Operating Humidity: 10%~90% non-condensing
• Storage Humidity: 5%~90% non-condensing
