5G/4G/3G |
|
Network Mode | • 5G NR:N1/N3/N5/N7/N8/N20/N26/N28/N38/N40/N41/N75/N76/N77/ N78 (2100/1800/850/2600/900/800/850/700/2600/2300/2500/150 0/1450/3700/3500 MHz)* • 4G FDD-LTE: B1/B3/B5/B7/B8/B20/B26/B28/B32 (2100/1800/850/26 00/900/800/850/700/1500 MHz)* 4G TDD-LTE: B38/B40/B41/B42/B43 (2600/2300/2500/3500/3700 MHz) • 3G WCDMA: B1/B5/B8 (2100/850/900 MHz) *N75/N76 and B32 only support downlink. |
Speed | 5G NR Speed • SA: Downlink: 7.01 Gbps, Uplink: 1.25 Gbps • NSA: Downlink: 4.5 Gbps, Uplink: 730 Mbps LTE Speed • Downlink: 1.6 Gbps, Uplink: 211 Mbps |
SIM Type | Dual Nano SIM |
SECURITY |
|
DPI | Deep Packet Inspection |
Access Control | Source/Destination IP Based Access Control |
Filtering | • Web Group Filtering (only in Standalone Mode) • URL Filtering • Web Security (only in Standalone Mode) |
ARP Inspection | • Sending GARP Packets • ARP Scanning (only in Standalone Mode) • IP-MAC Binding |
Attack Defense | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
HARDWARE FEATURES |
|
Interface | 1×2.5G RJ45 Port |
Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) • 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
Button | Reset Button |
Power Supply | • 802.3at PoE: 42-57V 0.6A • Passive PoE: 48V 0.375A |
Flash | 4GB eMMC Flash |
DRAM | 2GB LPDDR4x |
LED | System, Network Type, Signal Strength |
Dimensions ( W x D x H ) | 7.2 × 4.3 × 1.4 in (183 × 110 × 36 mm) |
Antenna | • 9× internal Cellular antennas • 1× internal Wi-Fi antenna |
SIM Slot | 1×Dual Nano SIM slot |
Mounting | Wall/Pole/Window Mounting |
Max. Power Consumption | 15.3W (802.3at PoE or Passive PoE) |
PERFORMANCE |
|
Concurrent Session | 500, 000 |
New Sessions /Second | 6,100 |
WIRELESS FEATURES |
|
Wireless Speeds | 2.4 GHz: 150 Mbps* *The Wi-Fi interface is used for local management purposes only. |
Wireless | • 802.11n: 6.5 Mbps to 150 Mbps (MCS0-MCS7, HT20/40) • 802.11g: 6, 9, 12, 18, 24, 36, 48 ,54 Mbps • 802.11b: 1, 2, 5.5, 11 Mbps |
Advanced Features | • Wireless Encryption: WPA/WPA2 Personal • SSID: 1 • Enable/Disable Wireless Radio • Enable/Disable SSID Broadcast • Automatic Channel Selection Algorithm • Transmit Power Control: Adjust transmit Power on dBm |
BASIC FUNCTIONS |
|
WAN Connection Type | 5G/4G/3G |
DHCP | • DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP |
Stateful ACL | Yes |
Quality of Service | Yes |
Bridge VLAN | Yes |
SMS | Receive / Send SMS |
VLAN | 802.1Q VLAN |
ADVANCED FEATURES |
|
Bandwidth Control | IP-based Bandwidth Control |
NAT | • Multi-Net NAT • Virtual Server • Port Triggering** • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP **These features are supported only in Standalone Mode. |
Routing | • Static Routing • OSPF** **These features are supported only in Standalone Mode. |
Session Limit | IP-based Session Limit |
TRANSMISSION |
|
NAT | • Multi-Net NAT • Virtual Server • Port Triggering (only in Standalone Mode) • NAT-DMZ • FTP/H.323/SIP/IPSec/PPTP ALG • UPnP |
Routing | • Static Routing • OSPF (only in Standalone Mode) |
Session Limit | IP-based Session Limit |
Bandwidth Control | IP-based Bandwidth Control |
AUTHENTICATION |
|
Web Authentication | • No Authentication • Simple Password* • Hotspot (Local User / Voucher* / SMS*/ Radius) • External Radius Sever • External Portal Sever • LDAP *These features are supported only in Controller Mode. |
MANAGEMENT FEATURES |
|
Omada App | Yes. |
Centralized Management | • Omada Central (Cloud-Based) • Omada Hardware Controller • Omada Software Controller • Omada App |
Cloud Access | Yes. |
Service | Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization) |
Maintenance | • Web Management Interface • Remote Management • Export & Import Configuration • SNMP v1/v2c/v3 • Diagnostics (Ping & Traceroute) • NTP Synchronize • Port Mirroring • CLI (only in Standalone Mode) • Syslog Support |
Management Features | • Automatic Device Discovery • Intelligent Network Monitoring • Abnormal Event Warnings • Unified Configuration • Reboot Schedule • Captive Portal Configuration |
OTHERS |
|
Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP _____________________________________________________ TDP Server Device discovery • Port: 20003 Protocol: UDP _____________________________________________________ DHCP Server Handle DHCP packets • Port: 67 Protocol: UDP _____________________________________________________ DNS Handle DNS packets • Port: 53 Protocol: TCP/UDP |
Certification | CE, NCC, BSMI, RoHS |
Package Content | • ER701-5G-Outdoor Gateway • Passive PoE Adapter • Mounting Kits • Waterproof kit • Quick Installation Guide |
System Requirements | • Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11 • MAC OS, NetWare, UNIX or Linux |
Environment | • Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F) • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F) • Operating Humidity: 5% to 95% non-condensing • Storage Humidity: 5% to 90% non-condensing • Surge Protection: 6 kV surge protection |
