Thermaltake AX500 Steel + TG Full Tower E-ATX Case - Snow (CA-11D-00F6WN-00)
AX Series white full‑tower (550×248×548 mm) with steel+TG panel, 4×CT140 fans (1500 rpm, 30.5 dBA), 8 expansion slots, USB‑C, USB‑3.0, HD audio, AIO radiators up to 420 mm, clearances: 185 mm CPU, 460 mm GPU, 200 mm PSU. 3‑yr case, 2‑yr fan warranty.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
Series
AX Series
Case Type
Full Tower
Dimension (H x W x D)
550 x 248 x 548 mm
(21.7 x 9.8 x 21.6 inch)
Panel
Steel + TG
Color
White
Material
SPCC
Cooling System
140 x 140 x 25 mm CT140 fan (1500rpm, 30.5 dBA) x 4
Drive Bays
5 x 3.5” , 1 x 2.5” or 6 x 2.5”
Expansion Slots
8
Motherboards
6.7” x 6.7” (Mini ITX), 9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX) ,
12” x 13” (E-ATX), SSI-CEB, SSI-EEB
Hidden-Connector Motherboard
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
I/O Port
USB 3.2 (Gen 2) Type-C x 1, USB 3.0 x 2, HD Audio x 1
PSU
Standard PS2 PSU (optional)
Fan Support
Front:
4 x 120mm ,3x 120mm , 2x 120mm , 1x 120mm
3 x 140mm , 2x 140mm , 1x 140mm
Top
3 x 120mm , 2x 120mm , 1x 120mm
3 x 140mm , 2x 140mm , 1x 140mm
Rear:
1 x 120mm , 1 x 140mm
Right:
3 x 120mm , 2x 120mm , 1x 120mm
2 x 140mm , 1x 140mm
Power Cover:
3 x 120mm , 2x 120mm , 1x 120mm
Radiator Support
Front (AIO):
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 420mm, 1 x 280mm, 1 x 140mm
Top (AIO):
1 x 360mm, 1 x 240mm, 1 x 120mm
1 x 420mm, 1 x 280mm, 1 x 140mm
Rear(AIO):
1 x 120mm , 1 x 140mm
Clearance
CPU cooler height limitation: 185mm(Max)
VGA length limitation:460mm(Max)
PSU length limitation: 200mm (Max)
*3 years warranty for the case
*2 years warranty for fan(s) inside the case
Product Name:
Thermaltake AX500 Steel + TG Full Tower E-ATX Case - Snow (CA-11D-00F6WN-00)
