HARDWARE FEATURES |
|
Standard & Protocol | IEEE802.3, IEEE802.3u,IEEE802.3ab，IEEE802.3bz |
CPU | Dual-Core 1GHz CPU |
RAM | 512MB |
Interface | 1*10/100/1000/2500Mbps WAN/LAN port 3*10/100/1000Mbps WAN/LAN ports |
Antenna | 5*external antennas |
Button | 1*Mesh/Reset button |
Power | Input: AC 100-240V~50/60Hz Output: DC 12V⎓1.5A |
LED indicator | 1* LED |
Dimensions | (L*W*H) 244*56*200mm |
WIRELESS FEATURES |
|
Wireless Standards | IEEE 802.11be/ax/ac/n/a 5 GHz IEEE 802.11be/ax/n/b/g 2.4 GHz |
Data Rate | 2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5350MHz(CH36-CH64) 5725-5850MHz(CH149-CH165) |
Frequency | 5 GHz: 4323 Mbps (802.11BE, HE160) 2.4 GHz: 688 Mbps (802.11BE) |
Transmission Power | SSID broadcasting and hiding MU-MIMO Beamforming signal directional transmission technology OFDMA |
Wireless Security | WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Security: Enable/Disable WPS(WiFi Protected Set-up) fast encryption |
SOFTWARE FUNCTION |
|
Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
Network Protocol | IPv4&IPv6 |
Operating Mode | Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） |
DHCP | DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation |
Parental Control | Client Filter URL Filter Time Limit |
Virtual Server | Port Forwarding DMZ Host UPnP |
Firewall | ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN |
DDNS | DynDNS, no-ip, oray, 88ip |
VPN | IPSec Transparent Transmission PPTP Transparent Transmission L2TP Transparent Transmission PPTP VPN Server PPTP VPN Client L2TP VPN Client |
Special Features | WAN/LAN Port Auto-Negotiation Wi-Fi+(Mesh System) Smart Diagnosis IPTV IPv6 Smart LED on/off |
Other Function | Support App and web management Bandwidth Control Guest Network MAC Address Clone Supports black list and white list Unify 2.4 GHz & 5 GHz Static Routing Remote Web Management Backup & Restore configurations Firmware upgrade online |
OTHER FEATURES |
|
Certification | CE, FCC,RoHS |
Temperature | Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
Package Content | Wi-Fi Router *1 CAT-6 Network Cable*1 NFC Sticker*1 Power Adapter*1 Quick Installation Guide*1 |
