Please Check Modem/Router Compatibility with your Service Providers Before Purchasing
SPECIFICATIONS:
HARDWARE |
| 4G Category | LTE CAT.6 | 4G/3G standards | FDD-LTE,TDD-LTE,WCDMA | Working band | FDD-LTE: B1/B3/B5/B7/B8/B20/B28 TDD-LTE: B38/B40/B41 WCDMA: B1/B5/B8 2CA: B1 + B1/B3/B5/B7/B8/B20/B28 B3 + B3/B5/B7/B8/B20/B28 B7 + B5/B7/B8/B20/B28 B38 + B38 B40 + B40 B41 + B41 | Max 4G speed | DL:300Mbps UL:50Mbps | Wi-Fi standards | 802.11b/g/n/ac | Wi-Fi frequency | 2.4GHz/5GHz | Wi-Fi speed | 2.4GHz:300Mbps 5GHz:867Mbps | Wi-Fi transmit Power | 2.4GHz:up to 20dBm 5GHz:up to 23dBm | Interface | 1 × 10/100/1000 Mbps LAN/WAN Port 1 × 10/100/1000 Mbps LAN Port 1 × Nano SIM Card Slot | Button | MESH/RST | Antennas | 2 External 4G/3G Antennas 2 External Wi-Fi Antennas | LED indicators | Internet Wi-Fi LAN 4G/3G Signal strength(3 Bars) | Dimensions（L*W*H） | 195*49.8*203.3mm | Weight | About 206g | Power supply | Power adapter:Input power AC 100V-240V 50/60Hz Output power:DC 12V==1A | SOFTWARE |
| WAN Type | 4G/3G or Wired Support Failover | Wi-Fi functions | Wi-Fi name & Wi-Fi key Channel & Bandwidth Guest Network Wi-Fi schedule Transmit power Beamforming+ WPS | Wi-Fi security | WPA-PSK, WPA2-PSK, WPA/WPA2 | Software features | APP/WEB DHCP Server VPN(PPTP Client/L2TP Client/OpenVPN Server) Firewall QOS Upgrade firmware from local or OTA IPV4/IPV6 | CERTIFICATIONS |
| Certifications | CE ROHS SIRIM NBTC | WORKING ENVIRONMENT |
| Temperature | Operating Temperature : -5℃~45℃ Storage Temperature : -40℃ ~70℃ | Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing | PACKAGE CONTENTS |
| Package lists | 1 * 4G LTE Router 1 * Ethernet cable 1 * Power adapter 1 * Quick Installation Guide |
|
