| Hardware Specifications |
| CPU | Quad core 717 MHz |
| Memory | 256 MB DDR3 |
| Antenna type | 2x2 MIMO high-performance internal antenna (2.4 GHz / 5 GHz) |
| LAN port | Gigabit (RJ-45) x 1 |
| WAN port | Gigabit (RJ-45) x 1 |
| External Ports | USB 3.0 x 1 (5V, 0.9A power output) |
| Button and switch | WPS, Power, Reset, Wi-Fi On/Off |
| Appearance |
| Size (Height x Width x Depth) | 154 mm x 199 mm x 65 mm |
| Weight | 0.45 kg |
| Temperature |
| Operating Temperature | 5°C to 40°C (40°F to 104°F) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Relative Humidity | 5% to 95% RH |
| Certification | - FCC
- CE
- BSMI
- VCCI Class B
- RCM
- KC
- iDA
- TELEC
- JATE
- IC
|
| Wi-Fi Certification | |
| Warranty | 2 Years |
| Others |
| AC Input Power Voltage | 100V to 240V AC |
| Power Frequency | 50/60 Hz, Single Phase |
| Power Consumption* | 12.95 W (Access)
5.21 W (Idle) |
| Wireless |
| IEEE 802.11ac | - IEEE 802.11a/b/g/n/ac
- Simultaneous tri-band Wi-Fi
- 5GHz-1: 867Mbps
- 5GHz-2: 867Mbps
- 2.4GHz: 400Mbps
|
| IEEE 802.11ac wave 2 | MU-MIMO |
| Wi-Fi Encryption | WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise, WPA2/WPA3-Personal, WPA3-Personal/Enterprise, Wi-Fi Enhanced Open (OWE) |
| Wi-Fi MAC address filter |
|
| Maximum MAC filters | 64 |
| Seamless roaming | 802.11k/v/r standard support |
| Beamforming |
|
| DFS |
|
| Schedulable Wi-Fi |
|
| Guest Network |
|
| Guest Portal |
|
| Customized page style |
|
| Connection time limit |
|
| Password Rotation |
|
| WPS 2.0 (Wi-Fi Protected Setup 2.0) |
|
| 3G/4G Dongle & Tethering (Learn more) |
|
| Maximum connected devices | 90 |
| Wi-Fi Point |
|
| Primary Wi-Fi Point |
|
| Network |
| Internet connection | Dynamic IP, Static IP, PPPoE, PPTP, DS-Lite (AFTR) |
| 3G/4G LTE dongle |
|
| Android tethering |
|
| iPhone tethering |
|
| Note | iPhone tethering only supported your Synology Router running SRM 1.2 or above |
| Operating mode | - Wireless Router
- Wireless AP
|
| Port forwarding | Setup via manual management or UPnP |
| Maximum port forwarding rules | 64 |
| Maximum UPnP rules | 64 |
| Port triggering |
|
| Maximum port triggering rules | 32 |
| Minimum port triggering timeout | 30s |
| Maximum port triggering timeout | 3600s |
| DMZ |
|
| IPv6 | IPv6 DHCP server / client, DS-Lite, 6in4, 6to4, 6rd, Dual-Stack, DHCPv6-PD, IPv6 Relay, FLET's IPv6 |
| DHCP | Server/client mode, client list, MAC address reservation |
| Maximum DHCP reservations | 500 |
| LAN/WLAN IGMP snooping |
|
| VPN | - VPN server (WebVPN, SSL VPN, SSTP, OpenVPN, L2TP/IPSec, PPTP, Site-to-Site)
- VPN client (PPTP, OpenVPN, L2TP/IPSec)
- VPN Pass-through (PPTP, IPSec, L2TP)
|
| Policy route, Static route, Network Address Translation (NAT), PPPoE relay |
|
| Maximum IPv4 static routes | 100 |
| Maximum IPv6 static routes | 100 |
| Diagnosis tools | |
| Safe Access |
| Parental Control |
| User Profile | 15 |
| Network Profile | 2 |
| Customized Internet schedule |
|
| Time Quota |
|
| IPv4/IPv6 DNS-based web filter | - Schedule
- Database
- Request to unblock
|
| Customized allow/block list | - Maximum blocked URLs: 100
- Maximum allowed URLs: 100
|
| Pause Internet |
|
| Reward |
|
| Log |
|
| Report |
|
| Security |
| Safe Search | Bing, Google, YouTube |
| Threat Intelligence Database | support in IPv4 & IPv6 |
| Google Safe Browsing | support in IPv4 & IPv6 |
| Database auto update | Threat Intelligence Database, Google Safe Browsing, DNS-based web filter |
| Traffic Control |
| Internet ban, device speed & priority |
|
| Application layer (L7) quality of service (QoS) |
|
| Maximum device rules | 64 |
| Maximum application rules per device | 32 |
| Traffic Monitor |
|
| Live view |
|
| Historical statistics | Daily, Weekly, Monthly, Annual |
| Website history |
|
| Application Detection |
|
| Traffic Report |
|
| Country auto update |
|
| Schedulable |
|
| Traffic analysis period | Daily, Weekly, Monthly, Annual |
| Export formats | .CSV, .HTML |
| VPN Plus Server |
| VPN Plus Server | Easily create and manage secure VPN access through a web browser or client. Supports various VPN services — Site-to-Site VPN, WebVPN, SSL VPN, Remote Desktop, SSTP, OpenVPN, L2TP over IPSec, and PPTP |
| Maximum Client VPN Access License | 10 |
| Site-to-Site VPN |
|
| Maximum Site-to-Site VPN Tunnels | 4 |
| Remote Desktop (RDP + VNC) | 3 |
| Connection List |
|
| Log |
|
| Report |
|
| Package Center |
| Cloud Station Server | Sync data from multiple platforms, centralizing it on the router while easily keeping historical versions of important files |
| Maximum Concurrent File Transfers | 64 |
| Note | Cloud Station ShareSync is not supported |
| DNS Server | Helps users find and translate domain names into IP addresses |
| Download Station | Supported download protocols: BT/HTTP/FTP/NZB/eMule |
| Maximum concurrent download tasks | 50 |
| Maximum concurrent BT download tasks | 20 |
| Media Server (DLNA/UPnP®) | - Media indexing
- DLNA Compliance
- PS3/PS4/Xbox 360/Xbox One supported
|
| RADIUS Server | Provides centralized authentication, authorization, and accounting for wireless network access |
| Mobile Apps |
| DS router (Android/iOS) | - First Time Installation
- Network overview
- Wi-Fi management
- Wi-Fi system topology
- Safe Access
- Traffic Control
- Network security (firewall, port forwarding, Internet ban)
- Wake on LAN
- System Update
|
| VPN Plus (Android/iOS) |
|
| DS cloud (Android/iOS) |
|
| DS get (Android) |
|
| DS file (Android/iOS) |
|
| Management |
| Operating system | Synology Router Manager (SRM) |
| Free OS upgrade |
|
| Anywhere access to SRM | Synology QuickConnect & Dynamic DNS (DDNS) |
| Security | Firewall/SPI Firewall, DoS Protection, VPN Pass-through (PPTP, IPSec, L2TP), Auto block, SSL certificate, Security Advisor, two-factor authentication |
| Wake on LAN (WOL) |
|
| WOL over QuickConnect |
|
| Maximum connected devices | 100 |
| Notification | Email, SMS, push service (via DS router) |
| SSH |
|
| SNMP |
|
| Configuration backup & restore |
|
| User account management |
|
| Printer server | Maximum printer: 1 |
| USB/SD Card File Service |
| File System | EXT4, FAT, NTFS, HFS+ |
| Access support | - File explorer (via LAN only)
- Web browsers: Chrome™, Firefox®, Internet Explorer®: 11 onwards, Safari® 11 onwards
- Mobile device: DS file
|
| Protocol support | Windows file service (CIFS), Mac file service (AFP), FTP/FTPS, WebDAV |
| Apple Time Machine |
|
| Shared Folder privileges |
|
| Storage hibernation |
|
| Environment & Packaging |
| Environment | RoHS Compliant |
| Packaging Content | - Main Unit X 1
- AC Power Adapter X 1
- RJ-45 LAN Cable X 1
- Quick Installation Guide X 1
|
