Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
The hot swappable drive feature is not supported by M.2 SSD slots.
Compatible drives are mandatory.
EXTERNAL PORTS
RJ-45 1GbE LAN Port
1
RJ-45 2.5GbE LAN Port
1
USB 3.2 Gen 1 Port
2
Notes
MTU value of 1GbE LAN port has a limit of 1500.
APPEARANCE
Size (Height x Width x Depth)
166 mm x 199 mm x 223 mm
Weight
2.18 kg
OTHERS
System Fan
92 mm x 92 mm x 2 pcs
Fan Speed Mode
Full-Speed Mode
Cool Mode
Quiet Mode
Brightness Adjustable Front LED Indicators
✓
Power Recovery
✓
Noise Level*
21.6 dB(A)
Scheduled Power On / Off
✓
Wake on LAN / WAN
✓
Power Supply Unit / Adapter
90 watts
AC Input Power Voltage
100V to 240V AC
Power Frequency
50/60 Hz, Single Phase
Power Consumption*
28.25 watts (Access)
6.10 watts (HDD Hibernation)
British Thermal Unit
96.33 BTU/hr (Access)
20.79 BTU/hr (HDD Hibernation)
Notes
For more information on how power consumption is measured, refer to this article.
Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.
