CPU | ARM 4-core Cortex-A55 2.0GHz processor |
CPU Architecture | 64-bit ARM |
Graphic Processors | Mali-G52 |
Floating Point Unit | ✓ |
Encryption Engine | ✓ |
Hardware-accelerated Transcoding | ✓ |
Neural Processing Unit (NPU) | ✓ |
System Memory | 4 GB on board (non-expandable) Note: Reserves some RAM for use as shared graphics memory. |
Maximum Memory | 4 GB on board (non-expandable) |
Flash Memory | 4 GB (Dual boot OS protection) |
Drive Bay | 2x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch bays: 3.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot-swappable | ✓ |
Gigabit Ethernet Port (RJ45) | 1 |
2.5 Gigabit Ethernet Port (2.5G/1G/100M) | 1 (2.5G/1G/100M) |
Wake on LAN (WOL) | ✓ |
Jumbo Frame | ✓ |
USB 2.0 port | 2 |
USB 3.2 Gen 1 port | 1 |
Form Factor | Tower |
LED Indicators | System Status, LAN, USB, HDD1~2 |
Buttons | Power, Reset, USB Copy |
Dimensions (HxWxD) | 165 × 102 × 220.6 mm Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18 inches high depending on model) |
Weight (Net) | 1.45 kg |
Weight (Gross) | 2.41 kg |
Operating Temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | Minimum 48W adapter (12VDC), 100-240VAC |
Power Consumption: Disk Standby Mode | 4.973 |
Power Consumption: Operating Mode, Typical | 13.907 W Tested with drives fully populated. |
Fan | 1 x 70mm, 12VDC |
System Warning | Buzzer |
Kensington Security Slot | ✓ |
Max. Number of Concurrent Connections (CIFS)
- with Max. Memory | 200 |
Package Contents | TS-216G Ethernet cable x 1 Power cord x 1 AC Adapter Flat head screw (for 3.5" HDD) x 8 Flat head screw (for 2.5" HDD) x 6 Quick installation guide (QIG) Drive tray keys x 2 |
Notes | Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting. |
