Keychron K10 Max ZMK Wireless Mechanical Keyboard (KBKCK10MSR9)
108-key K10 Max ZMK with silent mechanical switches, double‑shot PBT OSA keycaps, 12 multimedia keys, 1000 Hz polling (wired/2.4 GHz) and 90 Hz Bluetooth 5.2, NKRO, 4000 mAh battery, macOS/Windows/Linux.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
Number of Keys
108 (100%)
Switches
Keychron Silent Mechanical Switch
Number of Multimedia Keys
12
Frame Material
ABS Keycap
Material
Double-shot PBT Keycap
Profile
OSA (OEM profile with spherical-angle)
Layout
ANSI
Polling Rate (2.4GHz and Wired Mode)
1000Hz
Polling Rate (BT Mode)
90Hz
N-Key Rollover (NKRO)
Yes for both wireless and wired modes
Battery
4000 mAh rechargeable li-polymer battery
Wireless Working Time
Up to 2 years (Lab test result may vary by actual use)
Connection
2.4 GHz / Bluetooth / Type-C wired
Bluetooth version
5.2
Bluetooth Device Name
Keychron K10 Max ZMK
Compatible System
macOS / Windows / Linux
Dimension
447.37mmx 139.82mm (17.61 x 5.50")
Weight
1530g / 3.37 lbs
Height without keycap (front)
23.7 mm (0.93")
Height without keycap (rear)
29.8 mm (1.17")
Height incl. keycap (front)
32.9 mm (1.29")
Height incl. keycap (rear)
40.1mm (1.57")
Typing Angle
3.43º, 7.26º and 10.06º
MCU
RTL8762GKU
Operating Environment
-10 to 50℃
Product Name:
Keychron K10 Max ZMK Wireless Mechanical Keyboard (KBKCK10MSR9)
