Boost Clock* : up to 3320 MHz (Reference card: 3130 MHz)
Game Clock* : up to 2780 MHz (Reference card: 2530 MHz)
Stream Processors
2048
Memory Clock
20 Gbps
Memory Size
16GB
Memory Type
GDDR6
Memory Bus
128 bit
Card Bus
PCI-E 5.0
Digital max resolution
7680 x 4320
Multi-view
3
Card size
L=281 W=118 H=40 mm
PCB Form
ATX
DirectX
DirectX 12 API
OpenGL
OpenGL 4.6
Recommended PSU
450W
Power Connectors
8 pin*1
Output
DisplayPort 2.1a x2
HDMI 2.1b x1
Accessories
VGA manual
Note
* “Boost Clock” is the maximum frequency achievable on the GPU running a bursty workload. Boost clock achievability, frequency, and sustainability will vary based on several factors, including but not limited to: thermal conditions and variation in applications and workloads. GD-151
* “Game Clock” is the expected GPU clock when running typical gaming applications, set to typical TGP (Total Graphics Power). Actual individual game clock results may vary. GD-147
