Home  > PC Parts  > Computer Parts  > Power Supply / PSU > Equites V700 700W 80+ Bronze Power Supply (PSU-EQ-V700)

Equites V700 700W 80+ Bronze Power Supply (PSU-EQ-V700)

700W Equites V700 PSU with 80 PLUS Bronze efficiency (up to 85%); active PFC, 50 A +12 V rail, 100 W combined +3.3/+5 V, full OCP/OVP/SCP protection, 250k h MTBF, 100‑240 V input.

Equites V700 700W 80+ Bronze Power Supply (PSU-EQ-V700)
  • Power-Supply-PSU-Equites-V700-700W-80-Bronze-Power-Supply-PSU-EQ-V700-5
  • Power-Supply-PSU-Equites-V700-700W-80-Bronze-Power-Supply-PSU-EQ-V700-3
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is back in stock?

Please enter a valid email address

   Your Store   Question Mark

Your store is set to:

Check live stock level
    • DELIVERY
    • Post In Stock
    NSW Pickup & Post
    • Post In Stock
    • Villawood Robot Super StoreIcon 3 Instant Pickup
    SA Pickup & Post
    • Post In Stock
    • Croydon Robot Super StoreIcon 3 Instant Pickup

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.

Specifications

  • Product Name:
    Equites V700 700W 80+ Bronze Power Supply (PSU-EQ-V700)
  • Model Number:
    PSU-EQ-V700
  • Brand:
    EQUITES
  • Warranty Period:
    2 Year

Description

Power-Supply-PSU-Equites-V700-700W-80-Bronze-Power-Supply-PSU-EQ-V700-2




SPECIFICATIONS:

DC Output

700W

Combined +3.3V & +5V

Not exceed 100W

Max. Current for +12V

50A

Input Voltage

100 ~ 240V

Input Frequency

50Hz ~ 60Hz

PFC

Active PFC

Efficiency

80PLUS

20%   ~  82%

50%   ~  85%

100% ~  82%

MTBF

250,000 hours

Operating temperature

0°C ~ 40°C

Output Protection

Over current protection

Over voltage protection

Short circuit protection

Certification

RCM, 80 PLUS Bronze

Dimension

150 mm (W) x 85 mm (H) x 140 mm (D)

Connector

Connector:

Mainboard (20+4Pin)

CPU (4+4Pin)

PCIE (6+2Pin)

SATA+IDE (SATA & IDE)

SATA+IDE (SATA & IDE)

Exposed length (Connector):

500mm (20+4)

600mm (4+4)

500mm (6+2) / 150 (6+2)

450mm (SATA) / 150 (SATA) / 150 (IDE)

450mm (SATA) / 150 (SATA) / 150 (IDE) / 150 (IDE)
