SPECIFICATIONS:
HARDWARE |
| Flash Memory | 32MB Flash | Expansion | USB 3.2 Gen 2 (10Gbps) Type C | HDD | 4 x SATA3 6Gb/s; 3.5"/2.5" HDD/SSD | Maximum Internal Raw Capacity | 88 TB (22 TB HDD x 4, Capacity may vary by RAID types) | Support | Supports Hot Swappable Drives | System Fan | 120mm x1 | Power Supply Unit / Adapter | 90W x1 | Input Power Voltage | 100V to 240V AC | Certification | FCC, CE, VCCI, BSMI, C-TICK, BIS, KCC, EAC | Applied Models | AS31, 32, 40, 61, 62, 63, 64, Nimbustor, Nimbustor Gen2, Drivestor, Drivestor Pro, Drivestor Lite, Drivestor Pro Gen2, Lockerstor, Lockerstor Gen2, Lockerstor Pro, Flashstor | OPERATION |
| Power Consumption | Operation: 24.68 W Disk Hibernation: 6.02 W | Operation Temperature | 0°C~40°C (32°F~104°F) | Humidity | 5% to 95% RH | SIZE AND WEIGHT |
| Size | 174(W)x170(H)x230(D) mm | Weight | 2.03 kg / 4.48 lbs | SOFTWARE |
| Operating System | ADM 4.2.4 Onwards | FILE SYSTEM |
| Internal Disk | EXT4, Btrfs | FEATURES |
| Storage Management | Support Multiple Volumes with Spare Drives Volume Type: Single, JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 Support for Online RAID Level Migration Support for RAID Capacity Expansion Hard drives in an expansion unit cannot be combined with NAS drives in the same RAID array. | MyArchive | Hot swappable design enables easy transfer or exchange of high amounts of data Up to 4 bays reserved for MyArchive docking purposes File system support: EXT4, NTFS, HFS+, Btrfs and exFAT Supports AES 256-bit encryption on EXT4 and Btrfs Supports Btrfs snapshots Supports decryption with a USB key | PACKAGE |
| Package Weight | 3.43 kg / 7.55 lbs | Package Size | 237(H) x214(W) x323(D) mm | Package Contents | AS5004U Unit x1 Quick Installation Guide x1 AC Power Cord x1 AC Power Adapter x1 USB 3.2 Gen 2 Type-A to Type-C Cable x1 Flat Head Screw (for 2.5" HDD) x16 |
|
