SPECIFICATIONS:
MAIN
Run time for load 1800W
29min 13s
Main Input Voltage
230 V AC 1 phase
Input voltage
220 V
240 V
Input Connection Type
IEC 60320 C20
Input voltage limits
105…300 V 40% load
180...285 V full load
Network frequency
40...70 Hz auto sensing
Output voltage
Rated power in W
1800 W
Rated power in VA
2000 VA
Output connection type
4 IEC 60320 C13
Bypass type
Internal bypass (automatic and manual)
Crest factor
3 : 1
Harmonic distortion
3 %
Maximum configurable power in VA
Maximum configurable power in W
UPS type
On-Line
Wave type
Sine wave
Half load runtime
00:12:00 800 W
Efficiency
88 % (full load)
Output frequency
50/60 Hz +/- 3 Hz sync to mains
COMPLEMENTARY
Additional information
Configurable for 220 : 230 or 240 nominal output voltage
Battery type
Lead-acid external included
Control panel
Multifunction LCD status and control console
Free slots
1
Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
UPS connectivity
Serial port
USB port
Available expansion slot
Surge energy rate
600 J
Cable length
1.5 m
Number of cables
Colour
Black (RAL 7010)
Height
336 mm
Width
335 mm
Depth
425 mm
Net weight
45.8 kg
Mounting location
Front
Mounting preference
No preference
Mounting mode
Not rack-mountable
USB compatible
Yes
Mounting position
Vertical
Tower
Number of power module filled slots
0
Number of power module free slots
Redundant
No
Range of product
Easy UPS On-Line
Product or component type
Uninterruptible power supply (UPS)
ENVIRONMENT
Product certifications
CE
UKCA
TISI
Standards
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Ambient air temperature for operation
0…40 °C
Ambient air temperature for storage
-20…50 °C
Storage altitude
0…15000 m
IP degree of protection
IP20
Relative humidity
0…95 % non-condensing
Storage Relative Humidity
Acoustic level
53 dBA
Heat dissipation
759 Btu/h
Operating altitude
0...3000 m
BATTERIES & RUNTIME
Lead-acid battery
Battery voltage
72 V
Extended runtime
Number of battery filled slots
Number of battery free slots
Battery recharge time
5.5 h
Battery life
3…5 year(s)
Battery charger power
525 W rated
